StarTech.com 10-Port USB 3.0 Hub with Power Adapter – Metal Industrial USB-A Hub with ESD & 350W Surge Protection – Din/Wall/Des

$346.20 (Incl. GST)

StarTech.com 10-Port USB 3.0 Hub with Power Adapter – Metal Industrial USB-A Hub with ESD & 350W Surge Protection – Din/Wall/Des

In stock

SKU: STARTECH.COM_HB30A10AME Category:

Print

Description

StarTech.com 10-Port USB 3.0 Hub with Power Adapter – Metal Industrial USB-A Hub with ESD & 350W Surge Protection – Din/Wall/Desk Mountable – High Speed USB 3.2 Gen 1 (5Gbps) Hub. Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-B, Hub interfaces: USB 3.2 Gen 1 (3.1 Gen 1) Type-A. Data transfer rate: 5000 Mbit/s, Product colour: Black, LED indicators: Power. Power supply type: AC, Power consumption (typical): 65 W, Input voltage: 100 – 240 V. Width: 55 mm, Depth: 198 mm, Height: 30 mm. Quantity per pack: 1 pc(s), Package width: 190 mm, Package depth: 295 mm

Industrial-Grade | 15kV Air | 8kV Contact | Metal | Mountable | DIN Rail | 5GbpsThis TAA compliant 10-port industrial USB 3.2 Gen 1 hub gives you the scalability and power supply flexibility you need in harsh industrial environments, product, and repair labs, conference rooms or office workstations. With its rugged industrial-grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments.Perfect for Harsh EnvironmentsThis industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-24V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities.Perfect for factory environments, the rugged hub also supports a wide operating temperature range (0°C to 70°C) and offers surge and ESD protection to each USB port, which can help prevent damage to your connected devices.Connect & Charge More USB DevicesDesigned for a high volume of connections, this robust USB 3.2 Gen 1 hub offers 10 connection ports, for connecting more USB devices and peripherals.The hub also supports USB battery charging specification 1.2, delivering up to 2.4A on any port to a maximum of 50W total, so you can charge your mobile devices faster than traditional USB ports allow.Locate the Hub Where You Need It MostWith versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets and included DIN mount rails, you can securely mount the USB 3.2 Gen 1 hub to most surfaces such as a wall, under a desk or rack.It supports wide-range 7-24V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities. You have the option to power the industrial hub by connecting the hub directly to an outlet with the included external terminal block power adapter, for more convenient and flexible installation.StarTech.com offers an external power adapter, ITB20D3250, sold separately. The universal DC power adapter can be used as an alternative, back up or replacement power supply for StarTech.com’s line of industrial USB hubs.Works with Older USB DevicesThe rugged USB hub supports the full 5Gbps bandwidth of USB 3.2 Gen 1 and is backward compatible with previous USB devices. You can connect your legacy peripherals alongside your newer USB 3.2 Gen 1 devices without any disruptions.The HB30A10AME is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Warranty: 2 Years

Additional information

Ports quantity

10

Brand

StarTech.com

Host interface

USB 3.2 Gen 1 (3.1 Gen 1) Type-B

Hub interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A

Data transfer rate

5000 Mbit/s

Product colour

Black

Plug and Play

Yes

Certification

RoHS, REACH, CE, FCC, TAA

Power consumption (typical)

65 W

Input voltage

100 – 240 V

Input current

1.4 A

Output voltage

20 V

Output current

3.25 A

Width

55 mm

Depth

198 mm

Height

30 mm

Weight

352 g

Package width

190 mm

Package depth

295 mm

Package height

70 mm

Package weight

1.4 kg

AC adapter included

Yes

Cables included

USB

Operating temperature (T-T)

0 – 70 °C

Mean time between failures (MTBF)

126106 h

Chipset

Genesys Logic – GL3523

Terminal block port

Yes

LED indicators

Power

DIN rail kit included

Yes

Storage temperature (T-T)

-20 – 85 °C

Operating relative humidity (H-H)

5 – 95%

Surge protection

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

10

Quantity per pack

1 pc(s)

Included power plug types

ANZ, EU, JP, NA, UK

Quick installation guide

Yes

UASP support

Yes

Power supply type

AC

Master (outer) case width

400 mm

Master (outer) case length

510 mm

Master (outer) case height

320 mm

Products per master (outer) case

14 pc(s)

Harmonized System (HS) code

84719000
