7-Port Industrial USB 3.0 Hub with ESD Protection~7-Port USB 3.0 Hub (5Gbps) – Metal Industrial USB-A Hub with ESD

$248.68 (Incl. GST) 7-Port USB 3.0 Hub – Metal Industrial USB-A Hub with ESD Protection & 350W Surge Protection – Din Rail, Wall or Des

In stock



Description 7-Port Industrial USB 3.0 Hub with ESD Protection~7-Port USB 3.0 Hub (5Gbps) – Metal Industrial USB-A Hub with ESD Protection & 350W Surge Protection – Din Rail, Wall or Desk Mountable – TAA Compliant USB Expander Hub. Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-B, Hub interfaces: USB 3.2 Gen 1 (3.1 Gen 1) Type-A. Data transfer rate: 5000 Mbit/s, Product colour: Black, Housing material: Steel. Power source type: DC, Input voltage: 7 – 48 V. Width: 54 mm, Depth: 145 mm, Height: 45 mm. Package width: 295 mm, Package depth: 190 mm, Package height: 69 mm

Industrial-grade | 15kV Air | 8kV Contact | Metal | Mountable | DIN Rail | 5 GbpsThis TAA compliant 7-port industrial USB 3.0 hub gives you the scalability you need in harsh industrial environments, product and repair labs, conference rooms or office workstations. With its rugged industrial grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments.Perfect for Harsh EnvironmentsThis industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-48V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities.Perfect for factory environments, the rugged hub also supports a wide operating temperature range (0°C to 70°C) and offers surge and ESD protection to each USB port, which can help prevent damage to your connected devices.Connect & Charge More USB DevicesDesigned for a high volume of connections, this robust USB 3.0 hub offers 7 connection ports, for connecting more USB devices and peripherals.The hub also supports USB battery charging specification 1.2, delivering up to 2.4A on any port to a maximum of 35W total, so you can charge your mobile devices faster than traditional USB ports allow.Locate the Hub Where You Need It MostWith versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets and included DIN mount rails, you can securely mount the USB 3.0 hub to most surfaces such as a wall, under a desk or offers an external power adapter, ITB20D3250, sold separately. The universal DC power adapter can be used as an alternative, back up or replacement power supply for’s line of industrial USB hubs.Works with Older USB DevicesThe rugged USB hub supports the full 5Gbps bandwidth of USB 3.0 and is backward compatible with previous USB devices. You can connect your legacy peripherals alongside your newer USB 3.0 devices without any disruptions.The ST7300USBME is backed by a 2-year warranty and free lifetime technical support.The Advantage

Warranty: 2 Years

Additional information

Ports quantity



Host interface

USB 3.2 Gen 1 (3.1 Gen 1) Type-B

Hub interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A

Data transfer rate

5000 Mbit/s

Product colour


Housing material




Input voltage

7 – 48 V


54 mm


145 mm


45 mm


325 g

Package width

295 mm

Package depth

190 mm

Package height

69 mm

Package weight

600 g

Cables included




Operating temperature (T-T)

0 – 70 °C

Mean time between failures (MTBF)

126106 h


Genesys Logic – GL3520

Terminal block port


LED indicators


DIN rail kit included


Storage temperature (T-T)

-20 – 85 °C

Operating relative humidity (H-H)

5 – 95%

Surge protection


Power source type


Master (outer) case width

397 mm

Master (outer) case length

511 mm

Master (outer) case height

326 mm

Products per master (outer) case

14 pc(s)

Terminal block included


Harmonized System (HS) code
