TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch

$179.89 (Incl. GST)

24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX), IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x, 294 x 180

In stock

SKU: TP-LINK_TL-SG1024D V6 Category:

Print

Description

What This Product Does
The TL-SG1024D Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1024D can save power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

TP-LINK Green Technology
This new generation TL-SG1024D Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.

High Performance
All 24 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1024D forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1024D work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.

Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Additional information

Basic switching RJ-45 Ethernet ports quantity

24

Brand

TP-LINK

Full duplex

Yes

Maximum data transfer rate

1 Gbit/s

Storage temperature (T-T)

-40 – 70 °C

Dimensions (WxDxH)

294 x 180 x 44 mm

Switch type

Unmanaged

Quality of Service (QoS) support

Yes

Gigabit Ethernet (copper) ports quantity

24

Power connector

DC-in jack

Supported network protocols

CSMA/CD, TCP/IP

Stackable

Yes

Product colour

Grey

Power over Ethernet (PoE)

No

Operating relative humidity (H-H)

10 – 90%

Operating temperature (T-T)

32 – 104 °F

Connectivity technology

Wired

Bandwidth

48 Gbit/s

Connectivity LEDs

Y

Heat dissipation

46.44 BTU/h

Jumbo frames support

Yes

Certification

FCC, CE, RoHS

Power requirements

100 – 240V, 50/60Hz

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Networking standards

IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

10G support

No

Cable types supported

Cat3, Cat4, Cat5, Cat5e

Flow control support

Yes

Auto MDI/MDI-X

Yes

MAC address table

8000 entries

Switching capacity

48 Gbit/s

Forwarding rate

35.7 Mpps

Store-and-forward

Yes

Rack mounting

Yes

LED indicators

Yes

Power consumption (max)

13.62 W

Storage relative humidity (H-H)

5 – 90%

Width

294 mm

Depth

180 mm

Height

44 mm

Package width

250 mm

Package depth

400 mm

Package height

80 mm

Package weight

1.95 kg

Supported data transfer rates

10/100/100 Mbps

Auto-negotiation

Yes

Power supply included

Yes

Networking features

Gigabit Ethernet
