TP-Link 8-Port Gigabit Desktop Network Switch

$42.61 (Incl. GST)

8-Port Gigabit Desktop Switch, 8 x Gigabit Ethernet, Green Ethernet, 4.6W, 15KB Jumbo, 8K Mac, 2Mb Buffer, Black

In stock

SKU: TP-LINK_TL-SG1008D V8 Category:

Print

Description

The TP-Link 8-Port Gigabit desktop switch TL-SG1008D provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Moreover, TL-SG1008D adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG1008D can save up to 80%* of the power consumption, making it an eco-friendly solution for your home or office network.

Gigabit Switch
Featured with 8 10/100/1000Mbps ports, TL-SG1008D greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green With Your Ethernet
You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG1008D 8-Port Gigabit Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

Power down Idle Ports
When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG1008D can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 80% reduction in power use.

Power Budget According to Cable Length
Ideally, shorter cable would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of the length.

Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Additional information

Basic switching RJ-45 Ethernet ports quantity

8

Brand

TP-LINK

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-40 – 70 °C

Switch type

Unmanaged

Gigabit Ethernet (copper) ports quantity

8

Power connector

DC-in jack

Stackable

No

Product colour

Black

Power over Ethernet (PoE)

No

Operating relative humidity (H-H)

10 – 90%

Heat dissipation

15.8 BTU/h

Jumbo frames support

Yes

Packet buffer memory

2 MB

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Networking standards

IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

10G support

No

Copper ethernet cabling technology

10BASE-T, 100BASE-TX, 1000BASE-T

Cable types supported

Cat3, Cat4, Cat5, Cat5e

Flow control support

Yes

Auto MDI/MDI-X

Yes

MAC address table

4000 entries

Switching capacity

16 Gbit/s

Store-and-forward

Yes

Rack mounting

No

LED indicators

Yes

Power consumption (max)

3.53 W

Storage relative humidity (H-H)

5 – 90%

Width

180 mm

Depth

90 mm

Height

25.5 mm

Package width

110 mm

Package depth

185 mm

Package height

85 mm

Package weight

300 g

Auto-negotiation

Yes

Power supply included

Yes

Input current

0.6 A

AC input voltage

100 – 240 V

AC input frequency

50/60 Hz

Cables included

AC

Fanless

Yes

DC input voltage

9 V

Ethernet LAN data rates

10,100,480,800,1000 Mbit/s

Jumbo frames

15000

Sustainability compliance

Yes

Package type

Box

User guide

Yes

Harmonized System (HS) code

85176990

Maximum cable length

100 m

Wall mountable

Yes

Power source

DC

AC adapter included

Yes

Compliance certificates

CE, Federal Communications Commission (FCC), RoHS
