4K HDMI Audio Extractor with 4K 60Hz Support

$154.81 (Incl. GST)

or 6 weekly interest-free payments from $25.80 with Laybuy 4K HDMI Audio Extractor – 4K 60Hz – HDMI Audio De-embedder – HDR – Toslink Optical Audio – Dual RCA Audio – HDMI Au

In stock



Description 4K HDMI Audio Extractor with 4K 60Hz Support. Product colour: Black. Maximum video resolution: 4096 x 2160 pixels, Video resolutions: 1280 x 720,1920 x 1080,1920 x 1200,3840 x 2160,4096 x 2160, Maximum refresh rate: 60 Hz. Audio output channels: 5.1 channels. Host interface: HDMI, Video in: HDMI, Video out: HDMI. Input voltage: 100 – 240 V, Operating voltage: 5 V, Operating current: 1 A

HDMI Audio De-embedder | HDR | Toslink Optical Audio | Dual RCA Audio | HDMI Audio

This 4K HDMI audio extractor lets you de-embed the audio from your HDMI video streams to create a distinct audio output that you can connect directly to a digital or analog audio device. Supporting HDMI 2.0 specifications, the de-embedder maintains 4K 60Hz resolutions to deliver a seamless video experience.

4K Video Performance

The HDMI sound splitter supports video resolutions up to 4K 60Hz (3840 x 2160) and high video bandwidth up to 18Gbps. It also supports High Dynamic Range (HDR) video pass-through, letting you enjoy lifelike images with incredible contrast, brightness and color, and greater luminosity compared to standard digital imaging.

Maximum Compatibility

Easily integrate HDMI 2.0 devices, such as your new 4K Blu-ray player, with your existing audio equipment or desktop speakers. The extractor isolates and extracts the audio signal from your HDMI cable and lets you output to digital optical audio or dual RCA audio devices . The integrated EDID management capabilities support 2-channel, 5.1-channel and pass-through audio modes.

The HDCP compliant HDMI audio de-embedder is compatible with dual-RCA composite adapters, giving you the flexibility to integrate the audio from your HDMI source into 3.5 mm audio applications using MU6MMRCA, MU3MMRCA or MUFMRCA (sold separately).

The compact extractor features a small footprint that blends discreetly into your hardware setup, for a uniform look.

HD202A is backed by a 2-year warranty and free lifetime technical support.

The Advantage

– Separate and send the audio from a 4K HDMI video signal to dedicated audio devices
– Supports the latest HDMI 2.0 specifications and HDR video pass-through
– Hassle-free connection with digital optical audio or Dual RCA audio devices

Warranty: 2 Years

Additional information

Product colour



External power adapter


Operating voltage

5 V


80 mm


90 mm


22 mm


320 g

AC adapter included


Package width

152 mm

Package depth

192 mm

Package height

50 mm

Package weight

470 g

Maximum video resolution

4096 x 2160 pixels

Host interface


Maximum refresh rate

60 Hz

Audio output channels

5.1 channels

Input voltage

100 – 240 V

Operating current

1 A

Input current

0.4 A

Power plug type

Type M

Operating temperature (T-T)

0 – 45 °C

Storage temperature (T-T)

-20 – 70 °C

Operating relative humidity (H-H)

10 – 90%

Included power plug types


Video resolutions

1280 x 720,1920 x 1080,1920 x 1200,3840 x 2160,4096 x 2160

Audio output

RCA + Toslink

Mounting bracket(s) included


Video in


Video out


Screws included


Number of screws


Harmonized System (HS) code
