StarTech.com 4-Port PCIe Gigabit Network Adapter Card

$339.77 (Incl. GST)

StarTech.com 4 Port PCIe Network Card – Standard Profile – RJ45 Port – Realtek RTL8111G Chipset – Ethernet Network Card – NIC Se

In stock

SKU: STARTECH.COM_ST1000SPEX43 Category:

Print

Description

Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks

This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution

This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.

The StarTech.com Advantage

– Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
– Realtek RTL8111G chipset for reliable performance
– Supports full-duplex flow control

Additional information

Connectivity technology

Wired

Brand

StarTech.com

Maximum data transfer rate

2000 Mbit/s

Host interface

PCI Express

Interface

Ethernet

Ethernet LAN (RJ-45) ports

4

Networking standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Ethernet LAN

Yes

Ethernet LAN data rates

10,1000,100 Mbit/s

Wake-on-LAN ready

Yes

Auto MDIX IEEE

No

Full duplex

Yes

Internal

Yes

Chipset

Realtek RTL8111G

LED indicators

Activity, Link

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Linux operating systems supported

Yes

Server operating systems supported

Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019

Operating temperature (T-T)

0 – 55 °C

Operating relative humidity (H-H)

5 – 95%

Width

120 mm

Depth

138 mm

Height

18 mm

Weight

95 g

Package width

209 mm

Package depth

145 mm

Package height

40 mm

Package weight

184 g

Storage temperature (T-T)

-40 – 75 °C

Harmonized System (HS) code

85176990

Flow control support

Yes

Cabling technology

10/100/1000BaseT(X)

Jumbo frames support

Yes

Master (outer) case width

446 mm

Master (outer) case length

521 mm
