MSI MAG A650BN UK PSU ‘650W, 80 Plus Bronze certified, 12V Single-Rail, DC-to-DC Circuit, 120mm Fan, Non-Modular, Sleeved Cable

$115.81 (Incl. GST)

MSI MAG A650BN UK PSU ‘650W, 80 Plus Bronze certified, 12V Single-Rail, DC-to-DC Circuit, 120mm Fan, Non-Modular, Sleeved Cables, ATX Power Supply Unit, UK Powercord, Black’

In stock

SKU: MSI_MAG A650BN Category:

Print

Description

MAG A650BN provides players with a safe, reliable, and efficient entry-level power supply option. Its core features include 80 PLUS Bronze certification, DC to DC circuit design, 12V single rail, active PFC, and low-noise fan. The MAG A650BN will be one of the best choices for players who are just getting started with looking into DIY computers. After installation, gamers can immediately enjoy a reliable performance experience without additional settings.

80 PLUS BRONZE CERTIFIED
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.

120MM LOW NOISE FAN
The fan’s sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.

DC TO DC CIRCUIT DESIGN
Adopted DC-DC circuit design reduces the instability of output voltage, and ads stability to the supply of power.

COMPREHENSIVE CIRCUIT PROTECTION
Supports OCP, OVP, SCP, OPP, OTP protection
mechanisms and provides comprehensive protection.

5-YEAR LIMITED WARRANTY
The MAG A650BN is proudly backed by a 5-year limited warranty, guaranteeing long term reliable operation.

Additional information

Total power

650 W

Brand

MSI

AC input frequency

50 – 60 Hz

AC input voltage

100 – 240 V

Product colour

Black

Purpose

PC

Width

150 mm

Depth

140 mm

Height

86 mm

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Bronze

Harmonized System (HS) code

84733020

Motherboard power connector

20+4 pin ATX

Peripheral (Molex) power connectors (4-pin)

2

ATX Power connector (24-pin)

No

Cabling type

Non-Modular

Cooling type

Active

Number of fans

1 fan(s)

Maximum input current (@110V)

10 A

Maximum input current (@220V)

5 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

110 W

Combined power (+5V)

110 W

Max output current (+3.3V)

20 A

Max output current (+5V)

20 A

Max output current (+5Vsb)

20 A

Efficiency

85%

Power protection features

Over current, Over power, Over voltage, Short circuit

Motherboard power cable length

60 cm

Number of SATA power connectors

5

EPS power connector (4+4 pin)

Yes

CPU power connector (4+4 pin)

Yes

Floppy disk drive connector

No

Fan diameter

12 cm

On/off switch

Yes

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

12.5 W

Max output current (+12V)

54 A

PCI Express power connectors (6+2 pin)

2

ATX power connector (20+4 pin)

Yes
