Additional information
| Processor manufacturer | AMD |
|---|---|
| Brand | ASUS |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Supported memory types | DDR5-SDRAM |
| Maximum internal memory | 192 GB |
| Memory channels | Dual-channel |
| Supported storage drive interfaces | M.2, SATA III, SlimSAS |
| RAID levels | 0, 1, 5, 10 |
| On-board graphics adapter | No |
| USB 2.0 connectors | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet |
| Component for | PC |
| Motherboard chipset | AMD X870E |
| Supported processor sockets | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Unbuffered memory | Yes |
| Supported storage drive types | HDD & SSD |
| Number of HDDs supported | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| EPS power connector (8-pin) | Yes |
| 12V power connector | Yes |
| RGB LED pin header | Yes |
| HDMI ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Motherboard form factor | ATX |
| Motherboard chipset family | AMD |
| Audio chip | Realtek ALC4082 |
| Cooling type | Passive |
| Power source type | ATX |
| Windows operating systems supported | Windows 11 |
| Number of M.2 (M) slots | 5 |
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| Width | 305 mm |
| Depth | 244 mm |
| Cables included | SATA |
| S/PDIF out port | Yes |
| WiFi-AP antenna jack | 2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Audio output channels | 7.1 channels |
| Number of chassis fan connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI version | 2.1 |
| Parallel processing technology support | Not supported |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Number of storage drives supported | 10 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
| DisplayPort version | 1.4a |
| RAID support | Yes |
| Quick installation guide | Yes |
| PCI Express x16 (Gen 5.x) slots | 2 |
| Supported memory clock speed (max) | 8600 MHz |
| Line-in | Yes |
| USB4 Gen 2x2 ports quantity | 2 |
| Product colour | Black |
| ECC сompatibility | ECC & Non-ECC |
| BIOS flashback button | Yes |
